Aspen Plate Fin Exchanger

Design and rate multi-stream plate-fin exchangers to optimize performance and ensure profitable operations.

Part of AspenTech’s Comprehensive and Rigorous HX Modeling Solution

Model with Precision and Speed

Quickly identify the most efficient design with accurate modeling of heat transfer and pressure drop for a wide variety of configurations.

Achieve Performance with Optimal Design

Model plate fin exchangers accurately to minimize primary energy consumption.

Monitor System-wide Operational Performance

Use rigorous plate fin heat exchanger models in conjunction with Aspen HYSYS® to understand system-level performance.

Designs You Can Trust

Proven modeling technology based on proprietary theoretical models and correlations backed by over 40 years of experimental study. Easily validate design with in-product access to source methods, models and data.
