Aspen Exchanger Design & Rating

Optimize CAPEX and OPEX by rigorously modeling heat exchangers within the larger process using a comprehensive set of rigorous HX models and seamless data flow across disciplines.

Comprehensive Set of Rigorous HX Models

Activated Exchanger Design and Rating

Fully incorporate heat exchanger designs within Aspen HYSYS and Aspen Plus to produce the most optimal designs at the right economics.

Up-to-Date Documentation

Access the full heat exchanger research library from HTFS. Comply with the latest ASME standards: BPV Section VIII Division 1 & 2, 2017 edition.

All Major HX Types

Design all major heat exchanger types, including shell and tube, fired heater, plate, plate-fin, coil-wound, air-cooled and more. Improve mechanical shell-and-tube exchanger design quality.

Vast Physical Property Database

Rely on a database with 37,000 components, 127 property packages and 5M+ data points and interaction parameters. Employ state-of-the-art activity coefficient models and equations of state.
